Spec

• External Dimensions: W 405 x D 495 x H (Water Tank 460 + Switchboard 240) mm
• Tank Inner Dimensions: W 300 x D 400 x H 200 mm
• Tank Effective Dimensions: W 300 x D 300 x H 200 mm Observation Window W 258 x H 143 mm
• Capacity: 22 L
• Temperature range: 0 °C to + 80 °C
• Temperature stability: within ± 0.05 °C (In the tank when the circulating pump is not ***d)
• Medium Liquid Available for Use: Water/Ethylene Glycol Brine
• Temperature Control: Digital Temperature Indication Controller PID Control System
• Timer: Operation with auto start or auto stop timer (MAX 99 hours 59 minutes)
• Heater: Sheathed wire 1 kW
• Refrigerator: Air-cooled 130 W HFC -134 a
• Cooling Capacity: 230 W (Approximately 200 kcal/h Water Temperature + 20 °C 50 Hz) * When Circulation Pump Is Not Used
• Circulation Pump (Combined Use with Stirring): 20 W Motor
• Stirring Part: Propeller Stirring Type
• Pump Part: Maximum Pump Head 2 m, Maximum Flow 10 L/min, Maximum Discharge Pressure 0.02 Mpa
• Circulation IN-OUT: Outer Diameter φ 12 Hose Port (Rp 3/8) Movable Type
• Safety Device: Leakage Breaker, Self-Diagnosis Function (HC: Excess Temperature Rise Prevention, LC: Low Temperature Prevention, Low Water Level, Refrigerator Protection Circuit, Temperature Sensor Anomaly, Refrigerator High Pressure Anomaly, Erroneous Setting Prevention)
• Materials: Inner Tank: Stainless Steel (SUS -304), Exterior: Steel Plate Baked Finish
• Accessories: Stainless Steel Shelf x 1 Set, Stainless Steel Lid x 1
• Power: 100 VAC 14 A 50/60 Hz, 2 m power cord
• Weight: approx. 38 kg
• Optional: The rubber feet can be changed to casters.
• *When the temperature in the tank is 40 °C or higher, the chiller is forcibly stopped by the action of the chiller protection circuit. Therefore, chillers cannot cool the tank within the temperature range of 80 °C to 40 °C.
