65-1790-80 Digital Multi Meter(Bluetooth) TA452PL

model: 65-1790-80
brand: ICHINEN TASCO CO., LTD.
category: toner

Product Description

Product Model: 65-1790-80Product Brand: ICHINEN TASCO C […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 65-1790-80
Product Brand: ICHINEN TASCO CO., LTD.

Features

  • Equipped with Bluetooth communication function to transfer measurement data easily. Support for iOS and Windows10 (Excel/AutoCAD).
  • International Safety Standards IEC61010-1 CAT.IV 300 V, CAT.III 600 V
  • True effective value system (True RMS)
  • Carrying case convenient for carrying is included as standard

Spec

  • Measuring range
  • Direct current voltage (DCV): 600.0 m/6.000/60.00/600.0 V (input resistance: about 10 megohms)
  • Alternating current voltage (ACV): 6.000/60.00/600.0 V (input resistance: about 10 megohms)
  • Resistance (ohms): 600.0/6.000 k/60.00 k/600.0 k/6.000 M/60.00 Mohms (Open voltage: about 1.8 VDC)
  • Capacitor capacity: 60.00 n/600.0 n/6.000 mu/60.00 mu/600.0 mu F
  • Frequency (Hz): 99.99 Hz/999.9 Hz/9.999 kHz/99.99 kHz (input resistance: about 10 megohms)
  • Diode test: open voltage/about 3.2 VDC
  • Communication interface: Bluetooth ® 4.2
  • Battery life: Bluetooth OFF/approx. 150 hours, Bluetooth ON/approx. 60 hours, BT continuous communication/approx. 30 hours (at room temperature of approx. 20 degrees Celsius)
  • Dimensions/Mass: 110 (H) x 56 (W) x 13 (D) mm/approx. 84 g (including battery), 120 (H) x 63 (W) x 28 (D) mm/approx. 135 g (when stored in case)
  • Accessories: Instruction Manual, Coin Battery (CR 2032), Portable Case (C-PM 300)
