Features

• The ECG Click Board is available as a separate item, MikroElektronika part MIKROE-2455. The target board requires an MCU with a minimum 10-bit ADC. Click board comes with the header strips soldered. ECG click mikroBUS™ Bundle. The MikroElektronika ECG Click Board is an accessory board that provides a simple method of adding electrocardiogram measurement hardware to a development platform. This starter kit variant provides the required electrodes and cables in addition to the ECG Click Board. Like all Click Boards the ECG Click fits the popular mikroBUS™ socket, creating a plug-in solution to add functionality, removing the need for hardware configuration. The ECG Click measures electrical activity of the heart through 3 electrodes taped to the skin that connect to the board via a 3.5mm jack. The circuity of the ECG click amplifies the electrical signals from the heart and filters out noise, providing a clean and clear signal for the mother development board. The MikroElektronika MikroPlot software, a free to download data visualisation tool, can be ***d to analyse the data generated and create an ECG plot. Features. Fits the popular mikroBUS™ socket 7-block design (protection, preamplifier, high-pass filter #1, amplifier, high-pass filter #2, low-pass filter, DRL circuit) Jumpers for setting output voltage range Trimmer potentiometer to adjust gain MCP609 Op Amp MAX6106 Voltage Reference IC ESD, Overvoltage and Overcurrent protection Analogue output (mikroBUS™ AN pin) 5 V power supply. Package Contents. 1 x ECG Click Board 1 x 3 Lead ECG Cable with 3.5mm Jack 30 x Single Use ECG Electrodes
