64-7909-25 Pocket Digital Tester EA707DF-3
model:
64-7909-25
category:
toner
Product Description
Product Model: 64-7909-25 Features DC Voltage: Range/20 […]
Contact Us
Product Details
Product Model: 64-7909-25
Features
- DC Voltage: Range/200 mV/2/20/200/250V Accuracy/± (0.8% rdg ± 5 Digits) (Maximum Accuracy) * Accuracy dep***s on the range. For details, refer to the Electrical Performance in the Owner's Manual.
- AC Voltage: Range/2/20/200/250V Accuracy/± (1.0% rdg ± 5 Digits) (Maximum Accuracy) * Accuracy dep***s on the range. For details, refer to the Electrical Performance in the Owner's Manual.
- Resistance: Range/200 Ω/2/20/200 kΩ/2/20MΩ Accuracy/± (1.0% rdg ± 5 Digits) (Maximum Accuracy) * Accuracy dep***s on the range. For details, refer to the Electrical Performance in the Owner's Manual.
Spec
- DC Current: 20/200 mA ± (1.2% rdg ± 5 Digits)
- AC Current: 20/200 mA ± (1.5% rdg ± 5 Digits)
- LC display: displaying: 1999 counts
- Size: 113 (W) x 56 (D) x 23 (H) mm
- Weight cookies: 101 g
- IP Protection grade — IP 40
- power supply: LR 44 x 2 pieces (Included)
- Diode test: open-circuit voltage: approximately 1.5 V
- Conductivity test: buzzer sound at 30 ohms or less
- F***: 250 mA/250 V, φ5 mm x 20 mm
- environment ***d condition: environmental pollution level II
- Temperature and humidity range: 0 °C to 40 °C/75 %RH or less (non-condensing)
- standards Compliant: CAT II 250 V EN 61326, EN 61010 -1, EN 61010 -2 031
