3-6835-01 Gas Mixer CUBE GM2
model:
3-6835-01
category:
toner
Product Description
Product Model: 3-6835-01 Features All-in-one unit integ […]
Contact Us
Product Details
Product Model: 3-6835-01
Features
- All-in-one unit integrating mass flow controller, control power supply, valves, check valves, and gas mixer.
- Regulates flow rates of 2～4 gas lines and supplies mixed gas.
Spec
- Model number: CUBEGM2
- Gas type: 2
- Size (mm): 315 x 298 x 250
- Correspondence gas: Air, N2, Ar, He, H2, CO2, O2
- Flow rate control range: Each gas F.S. 10SCCM - 50SLM (however, Total flow rate of each gas is 100SLM or less)
- Flow rate setting: Variable with 10 rotation potential meter
- Flow rate setting/output display: Scaling display
- Settings/output display switching: Toggle switch
- IN, OUTLET valve: Ball valve
- Gas contact unit material: Stainless steel (SUS316), PTFE (poly tetrafluoroethylene), Fluorine rubber
- Fittings: Equivalent to 1/4in.SWL
- External leak: 5 x 10^ - 7Pa, m3/sec He
- Input power: AC100V
- Usage environments: Temperature/5 - 50℃ (accuracy guaranteed range: 15 - 35℃), Humidity/30 - 80% (no condensation)
- Accessories: AC cable (2m)
