Spec

• Specifications: Simple Pressure Vessel
• Can Body Dimensions: Φ 240 x 550 mm
• external dimension : 485 x 470 x 949 mm
• usable capacity: 25 L
• Total capacity: 28 L
• Kamata material: SUS304
• Thermometer: 5.0 to, 123.9 ° C
• Selection Course: Liquid Course, Instrument Course, Waste Course, Agar Course, Melting Course/8 Memory
• Temperature Setting (Variable): Sterilization/105 to 121 ° C, Melting/60 to 100 ° C, Heat Retention/45 to 60 ° C
• Lid Lock Temperature: Liquid/Agar/Melting Course/60 to 95 ° C Variable, Instrument/Waste Course/60 to 97 ° C Variable
• * The upper limit may vary dep***ing on the boiling point.
• Time Setting: Sterilization/1 to 250 min/remaining time display method, Melting/1 to 60 min/remaining time display method, Reservation/1 min to 1 week later/time setting method, Air vent/3 to 9 min variable method
• Exhaust setting: 3 levels (No, very little, very little)
• maximum working pressure : 0.137 MPa
• Pressure Gauge: Digital Display/0 to 0.3 MPa, Analog Display/0 to 0.4 MPa
• Safety Alarm Devices: Pressure Safety Valve, Leakage and Overcurrent Breaker, Dry-Heating Prevention Device, Alarm Indication (Empty Heating/Temperature Sensor Disconnection/Overtemperature/Supercooling/Overpressure/Lid Error/open and close Lever Lock Error)
• power supply: AC100V 50/60 Hz 15 A
• Power Consumption : 1.5 kW
• power supply Connection Shape: 3 m with Earth
• Weight: 44 kg
• Accessories: Wire Mesh Basket x 2 pieces/Exhaust Bottle/Drainboard/Drain Hose (50 cm)/Exhaust Hose (50 cm)/Drain Recovery Bottle/Insulok/Castor Stopper/Warranty/User's Manual/Self-Inspection Confirmation Letter
• *This product is not a medical device, please *** for research and development.
• *Cannot be ***d on Sterilization such as medical devices.
