Spec

• Display: 1999 count liquid crystal display
• measurement item: DC voltage, AC voltage, DC current, resistance, continuity check, diode check, battery check
• Measurement range (* Maximum Accuracy): DC Voltage: 200 m/2000 m/20/200/600 V * ± (0.5% rdg + 2 dgts), AC Voltage: 200/600 V * ± (1.2% rdg + 3 dgts), DC Current: 200 μm/200 m/10 A * ± (1.0% rdg + 2 dgts), Resistance: 200/2000/20 k/200 k/20 MΩ * ± (0.8% rdg + 2 dgts)
• Diode Check: Measure Diode Forward Voltage
• Continuity check: Alarm (buzzer) sounds at approx. 10 Ω or less
• battery Check: 1.5 V/9 V/12 V
• Maximum input voltage: DCV 600 VDC/ACpeak, ACV 600 Vrms
• Maximum input current: 200 mA (μA/mA range), 10 A (10 A range)
• Input Impedance: Approx. 10 MΩ or More (DC Voltage Range)
• Sampling rate: 2 to 3 times/second
• F***: 0.2 A/250 V (φ 5 x 20 mm) Ceramic Quick Blow F*** 1 piece, 10 A/250 V (φ 5 x 20 mm) Ceramic Quick Blow F*** 1 piece
• Power Supply: AAA size type battery 2 pieces
• battery Life: About 150 hours (No backlight, when using alkaline battery)
• Dimensions: 77 (W) x 134 (H) x 47 (D) mm
• Weight: about 206 g (Protective cover, including battery)
• Accuracy
• DC Voltage: ± (0.5% rdg + 2 dgts)
• AC voltage: ± (1.2% rdg + 3 dgts)
• DC Current: ± (1.0% rdg + 2 dgts)
• Resistance: ± (0.8% rdg + 2 dgts)
• Certificates: with General calibration certificate
• *The name and address of the person who requested the certificate will be blank.
• *Delivery will take about 2 weeks beca*** we will proofread it after the order is confirmed. (However, please **** that there will be additional days during the New Year's holiday.)
• *As this is a build-to-order product, we cannot accept returns after shipment.
