Spec

• Purification Method: RO → Ion Exchange → UV Lamp → [Tank] → Filtration
• Performance: Purified Water/Ion-exchange Water, Ion-exchange Water Purification Rate (approx. L/h) (at Water Temperature 25 °C)/12, Ion-exchange Water Sampling Rate/Max. 3 L/min (with Variable Sampling Rate Function), Ion-exchange Water Sampling Rate Setting Range/0.1 L to 100.0 L (0.1 L Units) or 10 mL to 9,990 mL (10 mL Units), Ambient Operating Temperature/5 °C to 35 °C
• Composition: Raw Water Filter/RO Pretreatment Cartridge 1 piece, RO Membrane Cartridge/1 piece x Spiral Type (Synthetic Thin Film), High Performance Ion Exchange Plastic Cartridge/One-Touch Connectable Cartridge (Mixed Bed Type 1.6 L) 1 piece, Final Filter/Hollow Fiber Filter (0.04 μm) 1 piece, Pressurized pumps (kPa)/400, UV Lamp/pure water Sterilization 1 piece (Circulation also sterilizes tank water), water quality Gauge/Digital Display (Specific resistance: display before and after temperature correction, temperature), Ion Exchange Water Storage Tank (Sold Separately)/Separate High Density Polyethylene (HDPE) 30 L, 60 L, 100 L (With Air Vent Filter) [With UV Lamp for Sterilization in Tank or Without UV Lamp], Ion Exchange Water water storage volume Display/Numeric Value (in 1 L increments) and Bar Graph Display, External Input/Output Signal/RS -232 C, Non-Voltage Contact Signal, for Tank Float Connection, UV Lamp Connection, for Sterilization, Tank Sterilization, UV Lamp Connection
• Raw water pressure range: 49 for kPa, to, 490 for kPa
• Raw water requirement: approx. 2.6 L/min
• external dimensions : W 319 mm x D 596 mm x H 608 mm
• power supply (50Hz/60Hz): AC100V 50Hz/60Hz Approx. 1.9 A
• Mass (approx. kg): 33.5
• Accessories: RO Pretreatment Cartridge 1 piece, High Performance Ion Exchange Plastic Cartridge 1 piece, UV Lamp 1 piece, Hollow Fiber Filter 1 piece, Original Port 1 piece, Water Supply Hose (With Connection Unit, inner diameter 9 mm x outer diameter 17 mm, 2 m) 1 piece, Tank Water Supply Tube (With Connection Plug, inner diameter 4 mm x outer diameter 6 mm, 3 m) 1 piece, pure water Water Supply Tube (With Connection Plug, inner diameter 6 mm x outer diameter 8 mm, 3 m) 1 piece, Drain Tube (inner diameter 6 mm x outer diameter 8 mm, 2 m) 1 piece, Drain Tube (inner diameter 4 mm x outer diameter 6 mm, 2 m) 1 piece, Butt 1 piece, Hollow Fiber Filter Cap 1 piece, External Signal Connector (with Leakage Sensor) 1 piece, External Water Supply Hose (3 m) 1 piece, power cord 1 piece, RO Membrane Cartridge 1 piece
