64-1204-12 Electrodialysis pure water Manufacturing Unit RO+EDI, 3 L/h RFV242EA
Product Description
Product Model: 64-1204-12Product Brand: ADVANTEC Featur […]
Contact Us
Product Details
Product Model: 64-1204-12
Product Brand: ADVANTEC
Features
- Since ion exchange resin is continuously regenerated, maintenance is very easy and running cost is low.
- Example of water quality analysis of purified water is A4 level by JIS K0557 type.
- The purification rate is about 3 L/h, about 5 L/h, about 10 L/h, and about 15 L/h. The tank capacity can be selected from 3 types: 30 L, 60 L, and 100 L. Various combinations are possible according to the amount of water ***d.
- Purified water can be transferred to other equipment, external water storage tanks, cleaning equipment, etc., and can also be ***d as a pretreatment device for ultrapure water production equipment.
- It is equipped with a UV lamp unit as standard and sterilizes the tank water by UV light during purification and circulation.
Spec
- Purification Method: RO → Ion Exchange → UV Lamp → [Tank] → Filtration
- Performance: Purified Water/Ion-exchange Water, Ion-exchange Water Purification Rate (approx. L/h)/3, Ion-exchange Water Sampling Rate/Max. 3 L/min (with Variable Sampling Rate Function), Ion-exchange Water Sampling Range/0.1 L to 100.0 L (0.1 L Units) or 10 mL to 9,990 mL (10 mL Units), Ambient Operating Temperature/5 °C to 35 °C
- Composition: Raw Water Filter/RO Pretreatment Cartridge 1 piece, RO Membrane Cartridge/1 piece x Spiral Type (Synthetic Thin Film), Ion Exchanger/Continuous Electrodialysis Regenerative Ion Exchanger (EDI Module), Final Filter/Hollow Fiber Filter (0.04 μm) 1 piece, Pressurized pumps (kPa)/500, UV Lamp/pure water Sterilization 1 piece (Circulation also sterilizes tank water), water quality Meter/Digital Display (Specific resistance: display before and after temperature correction, temperature), Ion Exchange Water Storage Tank (Sold Separately)/Separate High Density Polyethylene (HDPE) 30 L, 60 L, 100 L (with Airvent Filter) [With UV Lamp for Sterilization in Tank or Without UV Lamp], Ion Exchange Water water storage volume Display/Numeric Value (1 L Increment) and Bar Graph Display, External Input/Output Signal/RS -232 C, Non-Voltage Contact Signal, for Tank Float Connection, UV Lamp Connection, for Sterilization, for Tank Sterilization, UV Lamp Connection, Remote Dispenser Connection
- Raw water pressure range: 49 for kPa, to, 490 for kPa
- Raw water requirement: approx. 2.6 L/min
- external dimensions : W 319 mm x D 596 mm x H 608 mm
- power supply (50Hz/60Hz): AC100V approx. 2.4 A
- Mass (approx. kg): 35.5
- Accessories: RO Pretreatment Cartridge 1 piece, UV Lamp 1 piece, Hollow Fiber Filter 1 piece, Main Opening 1 piece, Water Supply Hose (With Connection Unit, inner diameter 9 mm x outer diameter 17 mm, 2 m) 1 piece, Tank Water Tube (With Connection Plug, inner diameter 4 mm x outer diameter 6 mm, 3 m) 1 piece, pure water Water Supply Tube (With Connection Plug, inner diameter 6 mm x outer diameter 8 mm, 3 m) 1 piece, Drain Tube (inner diameter 6 mm x outer diameter 8 mm, 2 m) 1 piece, Drain Tube (inner diameter 4 mm x outer diameter 6 mm, 2 m) 1 piece, Butt 1 piece, Hollow Fiber Filter Cap 1 piece, External Signal Connector with Leak Sensor 1 piece, External Water Supply Hose (3m) 1 piece, power cord 1 piece, RO Membrane Cartridge 1 piece
