Spec

• Number of Cartridges: 250 mm x 1 piece
• Applicable Cartridge Filter Shape Codes: C, F (Flat Gasket DOE) and TCW Type
• IN/OUT Shape: 3/4 "PTF (3/4" with PT Nipple)
• Dimensions : overall height ( mm )/340 , full width/200 mm
• maximum working pressure: 0.49 MPa (25 °C), 0.19 MPa (60 °C)
• Maximum operating temperature: 60 °C
• material: Head/Polypropylene, Trunk/Polypropylene, O-Ring/Silicone (Standard), Vent/SUS304 (Push Button Type/Standard), Adapter/Polypropylene, Adapter Spring/SUS304 (Standard), 3/4 "PT Nipple/Polypropylene
• Mass (kg): 0.84
• Pressure gauge: none (typical)
• *Cannot be ***d for gas filtration.
• *Autoclave Sterilization is not available.
• *Wrap the sealing tape around the piping taper screw.
• *This product ***s plastic, so it will deteriorate over time.
• *The degree of deterioration varies dep***ing on the temperature, pressure, and chemical history of the operating conditions. If any abnormalities are found, replace the product with a new one or replace parts sold separately.
• *Do not connect metal piping directly to the head.
• *Do not tighten the vent plug or drain plug with a tool such as monkey wrench.
