Spec

• Effective filtration area (cm2): 570
• pore size ( μm ) : 0.20
• maximum working pressure: 0.39 MPa (25 °C)
• Maximum operating temperature: 60 °C
• Sterilization Method * 2: EOG, Autoclave * 3
• Bubble Point (Isopropyl Alcohol) (MPa): ≥ 8.8 x 10 ^ -2
• material: Filter/PTFE, Support Media/Polypropylene, Other/Polypropylene
• hydrophobicity
• Dimensions ( φ 77 mm x Total length mm ) * 4 : 102
• IN/OUT Shape: 1/4 "NPTM
• *・・・ CCF-005, A 10 membrane filter ***s 2 pieces's different pore size membrane filter bonded together.
• *2 ・・・ Repeated autoclave sterilization may damage the filter. It is recomm***ed to perform a filter integrity test before ***.
• *3 ・・・ 121 °C 30 minutes
• *4 ・・・ Dimensions whose IN and OUT shapes are H-cord products
