Spec

• Effective filtration area (cm2): 450
• pore size ( μm ) : 0.20
• bacteria elimination performance : > LRV7 (P. diminuta)
• Maximum working pressure: 0.39 MPa (25 °C)
• Maximum operating temperature: 80 °C
• Cleaned * 1
• Sterilization method * 2: EOG, autoclave * 3, inline steam * 4
• Bubble point (water) (MPa): ≥ 0.39
• material: Filter/Polyethersulfone, O-Ring/Silicone (Standard), Other/Polypropylene
• Dimensions ( φ 62 mm x Total length mm ) : 48
• *1 ・・・ Cleaning is ultrapure running water of 10 L for Dimensions code C, 20 L for Dimensions code D, and 40 L for Dimensions code E.
• *2 ・・・ Repeated autoclaving or inline steam Sterilization may damage the filter. It is recomm***ed to perform a filter integrity test before ***.
• *3 ・・・ 121 °C 30 minutes
• *4 ・・・ 126 °C for 30 minutes (Differential Pressure 0.019 MPa)
