Features

• NUCLEO-F413ZH Nucleo-144 Development Board. This STM32 Nucleo-144 board provides an affordable and flexible way for ***rs to build prototypes with the STM32F413ZHT6 microcontroller. The Zio connector, which is an extension of Arduino Uno, provides access to more peripherals and with the ST morpho headers expands the functionality with a choice of Shields. The integrated ST-LINK/V2-1 debugger/programmer comes with the STM32 comprehensive software HAL library, software examples, as well as direct access to the ARM mbed on-line resources. Supported by wide choice of Integrated Development Environments (IDEs) including IAR, Keil, GCC-based and ARM mbed. STM32F413ZHT6 100MHz Cortex-M4F core microcontroller with 1.5MB Flash memory, 320KB SRAM Adaptive real-time accelerator (ART Accelerator™) allowing 0-wait state execution from Flash memory Up to 24 serial communication interfaces: USART, IrDA, I²C, SPI, LIN, CAN, USB, I²S, SDIO True random number generator CRC calculation unit RTC with subsecond accuracy and hardware cal***ar 96-bit unique ID Full access to all GPIO with ST Zio connector (Arduino Uno v3 connectivity support) ST morpho extension pin headers for access to all GPIO ST-LINK/V2-1 debugger/programmer with SWD connector Flexible board power supply USB OTG or FS Device with micro-AB connector 3 x LEDs: Power LED, USB communication, User LED User and Reset pushbuttons 32.768 KHz crystal oscillator ARM mbed Enabled (mbed.org)
