Spec

• Operating temperature range: R.T. + 10 °C, to 200 °C
• Temperature Adjustment Precision: ± 0.2 °C at Liquid Temperature 180 °C
• Temperature distribution accuracy: ± 0.5 °C at liquid temperature 180 °C
• Temperature rise time: about 120 minutes, from R.T. to 200 °C
• Ambient operating temperature: 5 °C, to 35 °C
• temperature controller: Microcomputer PID Control (TC-SVI)
• Operation type: Standard Operation, Program Operation (maximum 100 steps) 1 minute, to 99 hours 59 minutes
• Temperature Sensor: Platinum Temperature Measuring Resistor Pt 100 Ω
• Heater: SUS316L Pipe Heater
• Heater capacity (kW): 1.7
• Stirring Method: Propeller Type
• Inner tank: SUS304
• Safety device: Self-diagnostic function (Overheating, temperature sensor error, heater disconnection, SSR short circuit, ambient temperature error), overheat prevention device, thermal f***, overcurrent/leakage breaker
• tank inner size [Effective Dimensions] (mm): W 450 × D 300 × H 250 [W 350]
• external dimensions ( mm ) : W 730 x D 395 x H 465
• tank inner capacity ( approx . L ) : 34
• shelf board Load tolerance: 10 kg/piece height Stepless adjustment
• power supply (50Hz/60Hz): AC100V 18 A
• Required power supply Equipment: AC100V 30 A
• Mass (approx. kg): 27
• Accessories: Stainless Steel Lid 1 piece, shelf board 1 piece (with strut 4 pieces)
