Spec

• convection formula : Blower type (Left Callout, Horizontal)
• Operating temperature range (°C): 40 °C to 300 °C
• Temperature adjustment precision (°C): ± 0.2 °C at 300 °C
• Temperature distribution accuracy (°C): ± 4 °C at 300 °C
• Temperature rise time: about 60 minutes, from R.T. to 300 °C
• Ambient operating temperature: 5 °C, to 35 °C
• temperature controller: Microcomputer PID Control (TC-SVI System)
• Operation type: Standard Operation, Program Operation (maximum 100 steps) 1 minute, to 99 hours 59 minutes
• Temperature sensor: K class thermocouple
• Heater: Stainless Steel Sheath Heater
• Heater capacity (kW): 6
• Blower Fan: Sirocco Fan (Aluminum)
• Interior: SUS304
• Door Packing: Silicone Rubber
• Safety device: Self-diagnostic function (Overheating, temperature sensor error, heater disconnection, SSR short circuit, ambient temperature error), indep***ent overheat protection device, blower overload protection device, control circuit protection f***, key lock function, overcurrent/earth leakage breaker
• inner dimension ( mm ) : W 600 x D 600 x H 1,150
• external dimensions ( mm ) : W 1,230 x D 990 x H 1,530
• Internal volume (approx. L): 414
• number of shelves pitch : Passage 20 , Section 50 , mm
• Exhaust Port: φ 72 mm
• Measurement Port: φ 22 mm Main Body Top 1 location
• power supply (50Hz/60Hz): 200 VAC Single-phase 32 A
• Required power supply Equipment: 200 VAC Single-Phase 40 A
• Mass (approx. kg): 370
• Accessories: shelf board 2 pieces, Shelf Bracket 4 pieces, Fixed metal bracket 4 pieces for Floor
