Spec

• convection formula : Blower type (Right Callout, Horizontal)
• Operating temperature range (°C): R.T. + 50 to 250
• Temperature Adjustment Accuracy (°C): ± 0.2 at 250
• Temperature distribution precision (°C): ± 3 at 250
• Temperature rise time: about 80 minutes, from R.T. to 250 °C
• Cleanliness: Class 100
• Ambient operating temperature: 5 °C, to 35 °C
• temperature controller: Microcomputer PID Control (TC-SVI System)
• Operation type: Standard Operation, Program Operation (maximum 100 steps) 1 minute, to 99 hours 59 minutes
• Temperature sensor: K class thermocouple
• Heater: Stainless Steel Sheath Heater
• Heater capacity (kW): 2.1
• Blower Fan: Sirocco Fan (Stainless Steel)
• Air filter: HEPA filter (collection efficiency: 99.97% or more for 0.3 μm particles)
• Interior: SUS304
• Door Packing: Silicone Rubber
• Safety device: Self-diagnostic function (Overheating, temperature sensor error, heater disconnection, SSR short circuit, ambient temperature error), indep***ent overheat prevention device, blower overload prevention device, blower reverse rotation prevention device, control circuit protection f***, key lock function, overcurrent/earth leakage breaker
• inner dimension ( mm ) : W 450 x D 450 x H 450
• external dimensions ( mm ) : W 990 x D 770 x H 1,540
• Internal volume (approx. L): 91
• number of shelves pitch : 7 stages 50 mm
• Measurement port: Rc 1/4
• power supply (50Hz/60Hz): 200 VAC 3-phase 9 A
• Required power supply Equipment: 200 VAC, 3 Phase, 15 A
• Mass (approx. kg): 245
• Accessories: shelf board 2 pieces, Shelf Bracket 4 pieces, Fixed metal bracket 4 pieces for Floor
