64-0829-76 IOR Logger TA452RL
Product Description
Product Model: 64-0829-76Product Brand: ICHINEN TASCO C […]
Contact Us
Product Details
Product Model: 64-0829-76
Product Brand: ICHINEN TASCO CO., LTD.
Features
- For investigation of insulation degradation of industrial machinery and air conditioning equipment.
- Support for Insulation Deterioration Detection on the Output Side of Inverters
- Devices equipped with logging functions that can be ***d for predictive analysis
- Two measurement modes dep***ing on the measurement target
- Power supply mode ... Power distribution lines and commercial power supply equipment
- Inverter mode ... Power distribution lines and equipment on the output side that are DC and frequency converted by a three-phase power supply inverter
Spec
- [ACV]
- measurement range: 0.0 V to: 600.0 V
- Accuracy (when using CT sensor φ 40 mm): ± (1% + 3 d)
- [power supply Mode]
- Io
- measurement range: 0.000 mA to: 999.999 mA
- Accuracy (when using CT sensor φ 40 mm): ± (1% + 40 d)
- Ior
- measurement range: 0.000 mA to: 999.999 mA
- Accuracy (when using CT sensor φ 40 mm): ± (1% + 40 d + IO x 0.005)
- MΩ
- measurement range: 0.00 MΩ to: 10.00 MΩ
- [Inverter Mode]
- Io
- measurement range: 0.000 mA to: 99.999 mA
- Accuracy (when using CT sensor φ 40 mm): ± (1% + 40 d)
- Ior
- measurement range: 0.000 mA to: 99.999 mA
- Accuracy (when using CT sensor φ 40 mm): ± (1% + 40 d + IO x 0.005)
- MΩ
- measurement range: 0.00 MΩ to: 10.00 MΩ
- Measurement circuit: Single-phase, 3-phase 3-wire, 3-phase 4-wire (Grounding circuit, inverter compatible with 3-phase power supply chisel)
- Input signal: Current/CT sensor (φ 40 mm/φ 68 mm/φ 110 mm), voltage/R, S, T, E or U, V, W, E (4 inputs)
- Sampling interval: about once per second
- Measurement Mode: power supply Mode, Inverter Mode
- AC detection method: Average value detection
- recording memory: internal flash memory
- Recorded interval: 1 s, 10 s, 30 s, 60 s, 10 m, 30 m, 60 m
