64-0829-73 Ior Leakage Monitoring Logger TA452KL
Product Description
Product Model: 64-0829-73Product Brand: ICHINEN TASCO C […]
Contact Us
Product Details
Product Model: 64-0829-73
Product Brand: ICHINEN TASCO CO., LTD.
Features
- Definitive version of leak inspection by Ior for those who are having trouble with maintenance of factories, buildings, etc.
- Simultaneous measurement of up to 4 systems, logging
- Support for various connection methods (Single Phase 2 Wire, Single Phase 3 Wire, Three Phase 3 Wire, Three Phase 4 Wire)
- Achieves high-precision lor measurement that is not affected by high frequencies
- Enables logging of lor in 200 ms, the fastest in the industry
- Lightweight and equipped with a rear magnet so that the unit can be attached as is
- Can also be ***d as a normal leakage current and load current logger
Spec
- External power supply: AC100 to 240 V (50/60 Hz) 7 VAmax
- Using battery: AA size alkaline battery (LR6) x 6 (continuous *** time: about 11 hours)
- Display/LCD display update: 160 × 160 dots monochrome liquid crystal display/0.5 seconds
- Memory Card: SD Card (2GB) * Standard Included
- personal computer Communications: USB Ver 2.0
- Accuracy guaranteed temperature and humidity range: 23 ± 5 °C relative humidity 85% or less (non-condensing)
- Operating temperature and humidity range: -10 to 50 °C Relative humidity 85% or less (non-condensing)
- Storage Temperature and Humidity Range: -20 to 60 °C Relative Humidity 85% or less (non-condensing)
- Applicable to standards: IEC 61010 -1 CAT IV 300 V, CAT III 600 V Degree of contamination 2 IEC 61010 -2 - 030, IEC 61010 - 031, IEC 61326
- external dimensions: 165 (L) x 115 (W) x 57 (D) mm
- Mass: about 680 g (including battery)
- Accessories: Measurement cord for voltage, AC adapter, ground code, USB cable, SD card 2GB, carrying bag, instruction manual, identification marker, installation manual, 6 x AA size alkaline battery (LR6), software
