64-0829-34 Data Logger for Current/Voltage Recording TA452GC
Product Description
Product Model: 64-0829-34Product Brand: ICHINEN TASCO C […]
Contact Us
Product Details
Product Model: 64-0829-34
Product Brand: ICHINEN TASCO CO., LTD.
Features
- Multi-Type Logger for Recording Load Current, Leak Current, and Voltage in One Unit
- 60,000 data can be recorded when using 1 channel, and 20,000 data can be recorded when using all 3 channels.
- For recording voltage, load and leakage current.
Spec
- Record Mode: Normal, Trigger, Capture, power supply Quality
- Operation method: Sequential comparison method (CH1 signal synchronous sampling)
- rating Maximum Operating Voltage: 9.9 Vrms AC 14 V Peak
- Number of inputs: 3 ch
- measuring method: true rms operation
- RMS interval: Approx. 100 ms
- Sampling interval: normal/trigger recording mode approximately 1.65 msec/CH
- Sampling interval: Capture recording mode approximately 0.55 ms (waveform: approximately 1.1 ms interval)
- Sampling interval: power supply Quality Record Mode Approx. 0.55 ms
- battery Voltage Warning: Four-level battery Mark
- Input over display: display when measurement range is exceeded "OL"
- Auto power off function: power supply is turned off about 3 minutes after switch operation (when recording is stopped).
- power supply: 6 VDC (AA size battery x 4 pieces)/external power supply (dedicated AC adapter)
- Can be ***d continuously: about 10 days (AA size Alkali battery LR6)
- Withstand voltage: 3536 VAC (50/60 Hz rms)/5 seconds
