64-0828-58 Portable Oxygen Monitor TA470XJ
Product Description
Product Model: 64-0828-58Product Brand: ICHINEN TASCO C […]
Contact Us
Product Details
Product Model: 64-0828-58
Product Brand: ICHINEN TASCO CO., LTD.
Features
- Implantable oxygen monitor ideal for preventing acid loss in tanks and manhole work. (Supports up to 30 meters)
- Sensor 2 year warranty. (Replacement frequency is 2 years, so running cost can be greatly reduced)
- Continuous *** time approx. 20,000 hours (2 AA alkaline batteries can be ***d continuously for approx. 20,000 hours)
- Dustproof and waterproof structure including the implantable sensor (equivalent to IP 67)
- Sensor cable is fixed to the winding part and real-time measurement is also possible. (Anti-dandruff band makes it difficult to unscrew cables)
Spec
- Gas to be detected: oxygen
- Detection range: 0 to 40.0 vol% (1 digit: 0.1 vol%)
- Indication accuracy: within 0.7 vol% of ±
- Alarm setting: 1st/2nd alarm: 18.0 vol% over alarm: 40.0 vol%
- Alarm Type: gas alarm/2 stages alarm, over alarm failure alarm/sensor connection/disconnection, battery voltage drop, calibration failure, system malfunction
- Alarm Method: Self-Retention
- Alarm operation: gas alarm: lamp blinking, buzzer strong/weak sounding, gas concentration value blinking, vibration failure alarm: lamp blinking, buzzer continuous pulse sounding, failure content indication
- Display: Liquid crystal 7-segment gas concentration display + gas name + status information display
- power supply Specification: Alkali battery AA size Type x 2 pieces
- Continuous Usage Time: Approx. 20,000 Hours (New battery, 25 °C, no alarm, no light)
- Operating temperature and humidity range: -20 to + 50 °C (no sudden change), 10 to 95 %RH (no condensation)
- pressure of *** Range: Atmospheric Pressure (80 to 110 kPa)
- Response time: 90% within 20 seconds (at 20 °C, ± 2 °C)
- Explosion-Proof: Intrinsic Safety explosion-proof (Explosion-Proof Grade: ExiaIICT4Ga)
- Protected grade — IP equivalent 67
