Spec

• Purification Method: Raw Water → RO → Ion Exchange → UV Lamp → [Tank] → Composite Cartridge → UV Lamp → Filtration
• Water Supply System: Directly Connected to Water Supply
• Purified Water: Super pure water Ion-Exchange Water
• Maximum purity (specific resistance): 18.2 MΩ · cm
• T O C (ppb): < 1
• Ion exchange water purification rate (about L/h): 3
• Super pure water Water Collection Speed: Max. 2 L/min (with Variable Water Collection Speed Function)
• Super pure water Water Collection Set Range: 0.1 L to 100.0 L (0.1 L units) or 10 mL to 9,990 m (10 mL units)
• Ambient operating temperature: 5 °C, to 35 °C
• Raw Water Filter RO Pretreatment Cartridge: 1 piece
• RO Membrane Cartridge (Piece): Spiral Type (Synthetic Thin Film) 1 piece
• Ion Exchanger: Continuous Electrodialysis Regenerative Ion Exchanger (EDI Module)
• Composite Cartridge: 1 piece for Distilled Water and RO Water
• Latter-stage composite cartridge: 1 piece for removing trace impurities
• Ultra pure water Final Filter: Hollow Fiber Filter (0.04 μm) 1 piece
• Pressurized pumps (kPa): 500
• UV Lamp for Ion-exchange Water: pure water 1 piece for Sterilization
• UV Lamp for Super pure water: Available
• water quality meter: digital display
• Ion Exchange Water Storage Tank: Separate High Density Polyethylene (HDPE) 30 L, 60 L, 100 L (With Air Vent Filter and UV Lamp for Sterilization in Tank)
• Ion Exchange Water water storage volume Display: Numerical (in 1L increments) and bar graph display
• External input/output signal terminals: RS -232 C * 3, for non-voltage contact signal, for tank float connection, for tank sterilization UV lamp connection, for remote dispenser connection x 2 (Super pure water Water Sampling, pure water Water Sampling)
• Raw water pressure range: 49 for kPa, to, 490 for kPa
• Raw water requirement: approx. 2.6 L/min
• external dimensions ( mm ) : W 359 x D 670 x H 608
• power supply (50Hz/60Hz): AC100V approx. 2.7 A
• Mass (approx. kg): 47
• Accessories: RO Pretreatment Cartridge 1 piece, UV Lamp for pure water 1 piece, Composite Cartridge 1 piece, Post Composite Cartridge 1 piece, Hollow Fiber Filter 1 piece, Main Port 1 piece, Water Supply Hose (With Connection Unit, inner diameter 9 mm x outer diameter 17 mm, 2 m) 1 piece, Tank Water Tube (With Connection Plug, inner diameter 4 mm x outer diameter 6 mm, 3 m) 1 piece, pure water Water Supply Tube (With Connection Plug, inner diameter 6 mm x outer diameter 8 mm, 3 m) 1 piece, Drain Tube (inner diameter 6 mm x outer diameter 8 mm, 2 m) 2 pieces, Drain Tube (inner diameter 4 mm x outer diameter 6 mm, 2 m) 1 piece, Butt 1 piece, Hollow Fiber Filter Cap 1 piece, External Signal Connector (with Leak Sensor) 1 piece, power cord 1 piece, UV Lamp for Super pure water 1 piece, RO Membrane Cartridge 1 piece
