Spec

• Rated capacity (R.C.): ±500.0 N (±50.00 kg)
• Visible range: ±500.0 N±50.. 00 kg
• Unit: N, kg (g) (can be displayed upside down)
• Measurement method: Normal measurement, plus peak measurement, minus peak measurement
• Display period: 1, 2, 3, 5, 10, and 20 times/s
• Sampling period: 1000 times/second
• Accuracy: ±0.2%R.C. and ±1/2 digit (at 23°C)
• Temperature effect: Gain ±0.01%LOAD/°C, 0 ±0.08%/R.C./°C (Zero point drift can be cancelled by the tracking function)
• Display: 4-digit LCD with numeric sign (The sign can be set arbitrarily for the load direction and can be displayed upside down.) Text height 12 mm, 3-digit LCD text height 7 mm, various display (1) "LO BAT" (battery voltage drop) (2) "BAT" (charging) (3) "OVR" (overload) (4) "PEAK" (peak hold mode)
• Overload capacity: 200%R.C.
• Tracking function: Yes (ON/OFF switchable)
• output signal
• USB: Yes (communication with PC is possible with dedicated communication software. Connection cable is standard.) Continuous transmission maximum 100 times/second
• RS-232C: Yes (communication with PC is possible with dedicated communication command. Connection cable is optional.) Continuous transmission maximum 100 times/second
• Analog: +/- 1 V (+/- output to the displayable range), accuracy +/- 50 mV, 12bit D/A converter type output update 1000 times/second windshield pullable, load resistance 10 kΩ or more
• Overload converter: Open collector output (up to 30 VDC/5 mA) Switch to either overload output or converter output
• Power
• AC adapter (9 V/200 mA DC) or built-in Ni-MH battery (Rechargeable) can be measured while charging.
• Battery life: Approximately 8 hours after fully charging
• Charging time: Up to 16 hours (***s automatically when fully charged)
• Auto power off function: 10 minutes (can be ***d continuously when AC adapter is connected), can be disabled
• Memory function: 1000 continuous memories/100 single memories/50 standard memories (3 different memory modes can be switched) Statistical function available (Max, Min, Peak, Average, Standard Deviation)
• Converter capability: yes (upper and lower limits)
• Operating temperature range: 0~40°C (without condensation), 35~85%RH (without condensation)
• Communication software: Free download from the dedicated communication software (USB compatible) website
• Size: Width 75 x Thickness 38 x Length 147 mm
• Weight: about 450 g
• Accessories: Measuring adapter (6 types), hanger, AC adapter, carrying case, dedicated USB cable
