Spec

• Supported force gauges: FGP-0.2~50,100, FGPX-0.2~50,100
• Measured load: 1000 N (100kgf)
• Load capacity: 1000 N (100kgf)
• Feed speed: 10~400 mm/min Set the speed using the operation panel.
• Stroke: 400 mm
• Display: Dot Matrix LCD Signed 4 Digits
• Movement speed indicator: 10~400 mm/min
• Distance indicator: 0.0~400.0 mm
• Number of repetitions displayed: 0~9999
• Operation Modes: MANU Mode/Move to Dog, JOG Mode/Scale Operation, SING Mode/Move Between Dogs Once, CONT Mode/Move Between Dogs Repeatedly, PROG Mode/Move Position of 5 Points
• USB: USB (for PC)
• Overload input: Stop at FGPX (FGP) overload signal
• Measurement table: 150 x 200 mm
• Operating temperature range: 0~45°C (non-condensing)
• Power: 100 VAC ±10%
• Computer software: Download load and distance data sent from Sympo HP, provided free of charge, with trigger function (Start ingesting data after the set load is reached) Allows setting of number of times of continuous data acquisition/with upper/lower limit judgment function
• Other: Emergency stop switch
• Weight: approx. 63 kg
• Accessories: Power AC Socket for Force Gauge, Connection Cable for FGPX (FGP), USB Cable
