Features

• USB Cable, User Manual, and Software on CD-ROM • RS Pro ISG-LF44 RF Signal Generator • RS Pro ISG-LF44 is a pocket-sized USB interface-compatible RF signal generator for *** with smartphones and tablets.
• Supports the frequency range from 35 MHz to 4400 MHz and provides continuous wave (CW) signal output without signal modulation.
• Supported modes include Fixed Frequency/Frequency Sweep/Frequency Hopping/Power Sweep.
• The ISG-LF44 CD-ROM (included) is a dedicated PC application program. Developed under the JAVA software structure, it supports the operating system (Windows 2000/XP/Vista/7/8/Linus/mAc OS X) through a USB interface.
• The ISG-LF44 app can be downloaded to Android 4.0 or later smartphones and tablets.
• Features and Benefits: Frequency Range: 34.5 MHz→4400 MHz Output Power Range: -30 dBm→0 dBm Continuous Wave Signal, Unmodulated Fixed Frequency/Frequency Sweep/Frequency Hopping/Power Sweep Mode -107 dBc/Hz Phase Noise @ 100 kHz Offset Frequency Resolution: 10 kHz PC USB Power Supply/Control External PC Software Supports Various Operating Systems Use: Fourier Theory Research for Education and Training Motherboard Circuit Measurement Wireless Communication Signal Measurement Remote Control Maintenance
