63-7830-87-90 【Global Model】Fine Oven (with Explosion Vent) DF412S DF412S
Product Description
Product Model: 63-7830-87-90Product Brand: Yamato Scien […]
Contact Us
Product Details
Product Model: 63-7830-87-90
Product Brand: Yamato Scientific Co., Ltd.
Features
- Precision thermostat with explosion vent
- Safety door (explosion vent)
- Equipped with interlock type door knob that firmly secures the body and door
- Interlock function
- Door fastening lock enables operation by fastening the door.
- There is an explosion detection switch in the ceiling, and the main power supply is shut off when it is activated.
Spec
- Circulation method: Forced convection and ventilation
- Operating temp. range: (Forced convection) RT+10～260℃
- Temp. gradient: 10℃ (at 260℃)
- Additional mechanism: Explosion preventive vent door, exhaust damper (manual operation)
- Internal dimentions(WxDxH): 450×450×450mm
- External dimentions(WxDxH): 1050×620×1240mm
- Internal capacity: 91L
- Power supply: AC220V 50/60Hz single phase 10A (plug is not included)
- Weight: Approx. 130kg
- Accessories: Stainless shelf (load capacity : 30 kg/pc) x 2, Shelf bracket x 4, Manual
