Spec

• Maximum throughput (vs. H2O) (L): 150
• Motor power (W): 220
• Motor input (W): 176
• Main engine: brushless DC
• Speed display: 7 segment LED
• Speed range (rpm): 0/6 to 2000
• Reverse rotation: no
• Intermittent operation: no
• Maximum viscosity (mPas): 100,000
• Maximum power of stirring shaft (W): 167
• Continuous Usage (%): 100
• Maximum torque of agitating shaft (Ncm): 400
• Maximum torque (gear I) (Ncm): 400
• Maximum torque (gear II) (Ncm): 80
• Speed range I (50 Hz) (rpm): 6~400
• Speed range II (50 Hz) (rpm): 30~2000
• Speed range I: minimum speed (60 Hz) (rpm): 6
• Speed range I: Maximum speed (60 Hz) (rpm): 400
• Speed range I: minimum speed (60 Hz) (rpm): 30
• Speed range II: Maximum speed (60 Hz) (rpm): 2000
• Speed control: Stepless
• Accurate speed setting (+/- rpm): 1
• Speed measurement error (n>300rpm) (+/-%): 1
• Speed measurement error (n<300rpm) (±rpm): 3
• Stirring Blade Fastener: Chuck
• Temperature display: no
• Fittings mounted (O) (mm): 10
• Chuck Range (mm): 0.5~10
• Shaft through hole diameter (mm): 10.3
• Push-through-when stopped: yes
• Stand Mounting: Extension Arm
• Diameter of support arm (mm): 16
• Length of support arm (mm): 160
• Torque display: no
• Speed control: electronic
• Normal torque (Nm): 4
• Timer: no
• Certified for *** in clean rooms: no
• Explosion-Proof Specifications: no
• Body Dimensions (W x H x D) (mm): 114 x 325 x 245
• Weight (kg): 7.8
• Allowable ambient temperature (deg. C): 5~40
• Permissible Ambient Humidity (%): 80
• DIN EN 60529 Standard Protection Class: IP 42
• RS 232 interface: no
• USB interface: no
• Analog output: no
• Voltage (V): 230
• Frequency (Hz): 50/60
• Output: 226
• Inspection item: Actual measured speed (display accuracy ±3rpm at 300 rpm)
• Stirring Blade Compatible Models: R 1342 (1-7327-01), R 1345 (4-2399-01), R 2302 (1-3152-03), R 1381 (1-3152-11), R 1382 (1-3152-07), R 1385 (1-3731-13), R 1388 (1-3731-14), R 1389 (61-0005-43), R 1311 (61-0005-36), R 1312 (1-7327-02), R 1313 (61-0005-37), R 1352 (1-3152-04), R 1302 (1-7327-03), R 1303 (61-0005-62), R 1375 (1-7327-04), R 1376 (1-3731-16), R 2311 (1-3731-17), R 1330 (1-3152-09), R 1331 (1-7327-05), R 1333 (1-3731-18), R 3000.1 (63-1288-95), R 3001.1 (63-1288-96), R -11 (1382 1342 -7327), R 1345 (-2399 2302 -3152), R 1381 (-3152 61 -43), R -3152 (1385 -3731-01), R -13 (1388 -3731-02), R -14 (1389 1352 -03), R -3152 (1 1311 61), R -36 (1 1312 -01)
