Spec

• Air Cooled/Sealed System Directional Circulation
• Temperature control method: Inverter frequency control
• Corresponding circulating water: drinking water
• Temperature adjustment range and accuracy: - 10 ~ 80 degrees C, +/- 0.1 ~ 0.2 degrees C
• Cooling capacity (at liquid temperature): 30 degrees C/1600 W (1376 kcal/h), 10 degrees C/1230 W (1057 kcal/h), -10 degrees C/660 W (567 kcal/h)
• External circulation capacity (50 Hz): maximum flow rate 14.7 L/min, maximum head 10.4 m
• Temperature setting/display: Sheet key input/digital display, minimum digit 0.1 degrees C
• Safety functions: Temperature controller self-diagnosis function, refrigerator overload, sensor malfunction, refrigerator high-voltage switch, refrigerator protection timer, float switch, SSR short circuit, heater disconnection, circulation pump thermal protector, anti-freeze flow switch, inverter alarm, leakage/overcurrent breaker
• Included features: emergency stop button, variable indep***ent overrise prevention
• External Input/Output: Alarm Output Terminal: Contactless Voltage (a Contact) Output 250 V/DC 30 V Max. 3 A
• Heater: 2 kW (SUS 316 L)
• Refrigerator/Refrigerant: Air-cooled output: 550 W/R 410 A
• Temperature sensor: Platinum temperature resistor Pt 100 ohm
• External circulation nozzle: Both discharge and return ports (Rc 3/8 female screw) 14 mm outer diameter hose mouth
• Water tank capacity: 3.6 L (liquid volume: 2.8 L)
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions: 340 x 440 (452) x 850 mm/* Dimensions in () include projections.
• Weight: approximately 53 kg
• Power input: 13.5 A, 2.7 kVA
• Power supply voltage: 200 VAC single-phase 50/60 Hz (* Power plug not included.)
• *Performance is measured at room temperature of 20 degrees Celsius, rated supply voltage, 50 Hz and no load.
• *Cooling capacity and external circulation capacity are plus or minus 10% of display capacity.
• *Flow control valve is not included. Purchase options separately.
• Code: 251840
