Spec

• Forced convection system
• Interior dimensions (width x depth x height): 450 x 456 x 450 mm
• Storage capacity (L): 92
• Temperature adjustment range: room temperature + 10 ~ 270 degrees C
• Accuracy: below +/- 1 degree Celsius
• Temperature distribution: Spatial temperature deviation 8 degrees C/temperature gradient 11 degrees C
• Temperature reach time: 60 minutes
• Temperature control, setting and display: Microcomputer P.I.D control SSR output, sheet key input, digital display
• Timer program function: Auto start, Auto stop, Auto start stop, 1 step/2 step mode
• Safety features: Door open, upper/lower limit alarm, sensor failure, heater break, SSR failure, ground fault/overcurrent breaker, variable indep***ent overrise prevention
• Heater: Stainless steel sheath heater 1.2 kW
• Shelf Board Load Capacity, Material: Uniform Distribution Max. 15 kg/Sheet, SUS 304
• Shelf Plates Included: 2
• Shelf Pitch/Number of Racks: 30 mm/11 Racks
• Interior and Door Packing Materials: NSSC 180, Silicon
• Vent/Cable holes: top surface 2 places phi 28 mm, right side 1 place phi 37 mm
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions (width x depth x height): 550 (565) x 593 (625) x 822 (836) mm/* Dimensions in () include projections.
• Mass (kg): about 52
• Power input/rated power: 13 A, 1.3 kVA/100 VAC 50/60 Hz
• Power cord: 2m
• Code: 252280
• *Performance is measured at room temperature of 20 degrees Celsius, rated power supply voltage, 50 Hz, no load, exhaust port and closed cable holes.
• *One shelf board is fixed to the bottom shelf.
• *Performance notation for temperature distribution conforms to JIS C 60068 -3 -5 JTM K 07 -2007 (Performance test method and performance display method of temperature test tank, Japan Testing Machine Industry Association).
