Spec

• Cooling/Circulation System: Air Cooled/Sealed System Directional Circulation
• Temperature setting range: - 20 ~ 30 C (without heater)
• Temperature control accuracy: +/- 2 degrees C
• Cooling capacity (at liquid temperature): 10 degrees C/1200 W (1030 kcal/h), 0 degrees C/950 W (820 kcal/h), -10 degrees C/650 W (560 kcal/h)
• External circulation capacity (50/60 Hz): maximum flow rate 12/14 L/min, maximum head 9.5/13 m (discharge pressure: 0.09/0.13 MPa)
• Temperature control: Refrigerator ON-OFF control
• Temperature setting/display: Sheet key input/digital display, minimum digit 1 degree C
• Safety functions: Leakage/overcurrent breaker, refrigerator high-pressure switch, overload relay holding circuit, refrigerator protection timer, f*** for service outlet, temperature controller self-diagnostic function, circulating pump thermal protector
• Accessory function: With flow stop valve
• External input/output: Communication terminal for vacuum controller (NVC -3000 type), communication terminal for evaporator (N -1210 B type)
• Refrigerator/Refrigerant: Air-cooled output: 650 W/R 407 C
• Cooling Coil: SUS 316 L
• External circulation nozzle: One-touch connector inner diameter 10 mm, one-touch hose nozzle outer diameter 10 mm
• Water Tank Materials, Dimensions, Capacity: SUS 304, Inner Diameter 280 x 270 mm, 16.5 L (Liquid Amount 14 L)
• Service Outlet: 100 VAC for Aspirator, Max. 4 A1 Unit
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions: 340 (354) x 384 x 851 (940)/* Dimensions in () include projections.
• Weight: 41 kg
• Power input/voltage: 11 A/1.1 kVA/100 VAC 50/60 Hz
• *Performance is measured at room temperature of 20 degrees Celsius, rated supply voltage and no load.
• *Cooling capacity is +/- 10% of display capacity.
• *The external circulation capacity is +/- 10% of the display capacity.
• *At room temperature of 35 degrees Celsius, the temperature to reach cooling is -10 degrees Celsius.
• *Pure water can not be circulated.
• Code: 268440
