Spec

• Fixed-width groove type
• Flow rate range: 0.06 ~ 180 mL/h
• Flow rate accuracy: within +/- 2% (repeatability: within +/- 1%)
• Maximum discharge pressure: 147 kPa (1.5 kg/cm 2)
• Maximum suction pressure: 9.8 kPa (0.1 kg/cm 2)
• Liquid viscosity/temperature: Max. 2 Pa/s (2000 cP)/0 ~ 60 degrees C (non-freezing)
• rotation settings: volume settings
• Display: 7-segment LED 4 digits
• Liquid feeding direction: forward/reverse switchable, with rapid function
• Motor: DC servomotor output: 15 W
• Driving circuit: Speed feedback servo control
• Tube case: PVC resin
• Number of tubes: 1
• Number of tube case tiers: 1 tier
• Usable tube materials: Silicon, Tygon (R), Versilon (Fullan (R)), Pharmed (R)
• Usable tube diameter: inner diameter 1.15 x outer diameter 3.2 mm
• Operating ambient temperature range: 0 ~ 40 degrees Celsius (noncondensing)
• External dimensions: 137 x 130 (148) x 178 (191) mm/* Dimensions in () include projections.
• Weight: approximately 2 kg
• 1 A, 100 VA, 100 VAC, 50/60 Hz
• *Performance is measured at room temperature of 20 degrees Celsius, rated power supply voltage, water, liquid temperature of 18 degrees Celsius, back pressure of 0, and specified silicon tube.
• *Tubes sold separately. Performance such as flow rate and discharge pressure varies slightly dep***ing on the tube ***d.
• Code: 251380
