63-1395-45 Small thin film evaporator MF-1000
Product Description
Product Model: 63-1395-45Product Brand: TOKYO RIKAKIKAI […]
Contact Us
Product Details
Product Model: 63-1395-45
Product Brand: TOKYO RIKAKIKAI CO., LTD.
Features
- Compact Flash Evaporator for Ease of Use
- For Concentrating Foaming and Thermally Sensitive Samples
- A small thin film evaporator that can be concentrated while suppressing the jolting and foaming of the sample beca*** the stirring blade rotating at high speed in the evaporator tube forcibly forms a thin film. Rotary evaporators can concentrate foaming samples that are difficult to concentrate.
- The structure is easy to handle, so it is easy to clean, and there is no need to core the motor.
- Cooling water can be circulated either by a one-touch joint or by a bamboo nozzle.
- The piping connection can be attached and detached with one touch.
Spec
- Speed range: 100 ~ 1200 rpm
- Evaporation capacity: Max. 760 mL/h (water evaporation)
- Reached vacuum: 399.9 Pa (3 Torr) or less
- Viscosity ***d: about 1000 cP
- Rotation setting and display: Volume setting and digital display
- Rotating shaft seal: Non-seal magnet coupling system
- Safety features: F*** (2A) Self-diagnostic (Overcurrent protection, overheat protection)
- Rotary motor: Brushless DC motor
- Evaporation tube: Jacket-type evaporation area: 0.025 m2
- Cooler: Vertical double serpentine cooling area: 0.14 m2
- Receiving flask: Concentration side/round flask 1L ball slide S 35/20, Distillation side/round flask 2L ball slide S 35/20
- Cooler/Evaporation tube/Connection diameter: One-touch connector inner diameter 10 mm, one-touch hose nozzle outer diameter 10 mm
- Vacuum drawing diameter: outside diameter of suction nozzle: 10 mm
- Wetted part material: borosilicate glass, SUS 304, Teflon (R)
- Heating source: Maximum temperature for *** with external hot water circulator (sold separately): 80 degrees C
- Operating ambient temperature range: 5 ~ 35 degrees C
- External dimensions: 490 x 350 x 930 mm
- Weight: approximately 17 kg
- Power input/voltage: 2 A, 200 VA/AC 100 V 50/60 Hz
- *Performance is measured at room temperature of 20 degrees Celsius and rated supply voltage.
- *Evaporation capacity is measured at water, hot water circulation temperature of 70 degrees Celsius and vacuum degree of 25 hPa.
- Accessory: One-touch hose for hot water circulation device connection 2m x 1
- Code: 248980
