Spec

• Decompression Concentration Using Centrifugal Force
• Speed range: fixed at 1400/1700 rpm (50/60 Hz)
• Temperature adjustment range: OFF, room temperature + 5 ~ 80 degrees C
• Reached vacuum: Internal pump: 40 hPa, External pump: 13.3 hPa
• Temperature control/setting/display: P.I.D control/digital setting/display
• Safety features: Fixed temperature overheat protection, motor brake (works when lid opens)
• Rotor: Sold separately (For Micro Tubes, Test Tubes)
• Heater: 140 W
• Vacuum seal: Magnet drive system (seal-less mechanism)
• Vacuum gauge: Bourdon tube type (- 100 ~ 0 kPa)
• Vacuum pump: Built-in (small diaphragm type vacuum pump)
• Nitrogen Purge/Disinfection Filter: Aperture 6.5 mm/Pore 0.2 mum
• Vacuum release valve: manual, slow leak mechanism
• Connection tube material: Teflon (R)
• Connector Material: PP
• Inside chamber dimensions and material: phi 160 x 105 mm, stainless steel (SUS 304)
• Lid Material: Clear PVC
• External pump exhaust connection diameter and material: outside diameter 8 ~ 10 mm, PP
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions: 240 (254) x 260 (310) x 260 mm/* Dimensions in () include projections.
• Weight: approximately 10 kg
• Power input/voltage: 2.4 A, 240 VA/AC 100 V 50/60 Hz
• *Performance is measured at room temperature of 20 degrees Celsius and rated supply voltage.
• Code: 260570
