Spec

• Vortex Decompression Concentration by Vibration
• Number of containers: Up to 8
• Shaking speed range: 100 ~ 1100 rpm (50/60 Hz)
• Amplitude: 3mm
• Temperature control range and accuracy of water tank: room temperature + 5 ~ 60.0 degrees C, + 0.2 degrees C
• Temperature control range in hood: 30 ~ 60 degrees C
• Time setting: 0 ~ 99 hours 59 minutes (minimum setting: 1 minute), Accumulating timer: 1 ~ 9999 hours
• Programs: Auto Start, Auto Stop, Step Program
• Vacuum indication and adjustment: Vacuum gauge and vacuum adjustment valve
• Safety features: Fixed temperature in water tank overheat inhibitor, water tank control self-diagnostic function (Heater break, sensor error, upper/lower temperature alarm, shaking motor error,) Leakage/overcurrent breaker, thermo-label (70 degrees Celsius)
• Water tank capacity and materials: 3L borosilicate glass, stainless steel
• Gas Contact Material: Teflon (R), PP, Viton, Silicon, Hard Glass
• Connection diameter: outside diameter of vacuum nozzle/leak nozzle 10 mm, outside diameter of water tank drain 12 mm
• External dimensions: 250 (300) x 420 (500) x 560 (670) mm/* Dimensions inside the () of depth and height are the maximum dimensions when the hot air hood is open.
• Weight: 22 kg
• Power input/voltage: 9.0 A, 0.9 kVA/100 VAC 50/60 Hz
• *Performance is measured at room temperature of 20 degrees Celsius, rated supply voltage, 50 Hz and no load.
• Accessories: Attachments for outer diameters of 16.5 and 18 mm (8 each), evaporator connection tube, orifice connector, ball joint clamp 1 each
• *Attachments for each size are required when attaching containers.
• *Optional attachment (sold separately) is required for containers with outer diameters of 12, 13 or 15 mm.
• Code: 248970
