Spec

• Vacuum setting range: 0 ~ 760 mmHg (Torr) , 0 ~ 1013 hPa (mbar)
• Vacuum measurement range: 0 ~ 800 mmHg (Torr) 0~1066hPa(mbar)
• Vapor temperature measurement range: 0 ~ 150 degrees Celsius (when a vapor temperature sensor is connected)
• Setting and control system: Dial type encoder, key input/solenoid valve ON-OFF or variable output voltage
• Pressure unit setting: mmHg, Torr, hPa, kPa, mbar
• Control Program: Constant Value, Solvent Program, Auto Eco Step Program
• Control items: Pressure, Temperature (Cooling Water, Bath Vapor), Auto Jack, Rotation ON-OFF, Voltage Output, Power ON -OFF
• Display: Color TFT LCD (4.3 inch)
• Items displayed: Operating mode, operating status, measured pressure, set pressure, vapor temperature (when connected to sensor sold separately), operating time, bath temperature, cooling water temperature, and rotary evaporator speed (when connected to communication cable)
• External inputs and outputs: common communication terminal for cooling water circulator, bus and rotary evaporator, NVC-NVC communication terminal, inverter pump communication terminal, pump control box communication terminal, vapor temperature sensor terminal, micro USB (for personal computer communication)
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions: 138.7 x 50 (64.5) x 114.2 mm/* Dimensions in () include projections.
• Weight: approximately 670 g
• Power input/voltage: 0.1 A, 10 VA/AC 100 ~ 240 V 50/60 Hz
• *Power cord: changeable by AC adapter
• Code: 269370
