Spec

• Water/oil bath included
• Speed range: 5 ~ 280 rpm
• Evaporation capacity: Max. 23 mL/min (water evaporation)
• Bath temperature adjustment range: room temperature + 5 ~ 180 degrees C
• Bath temperature adjustment accuracy: +/- 1.5 degrees C (oil: +/- 3 degrees C)
• Rotation setting and display: Volume type and rotation speed digital display
• Jack function: electric lift (100 mm) + manual slide (130 mm)
• Bus safety features: F***s, fixed temperature overheat protection, absolutely protective bus cover
• External input/output: NVC -3000 type communication terminal, communication terminal for cooling water circulator
• Rotating motor: Stepping motor
• Glass set: Vertical double serpentine cooling area 0.146 m2, adapter, rotary joint (inner diameter 18 x total length 178 mm TS 29/38), sample flask (eggplant type) 1 L (TS 29/38), receiving flask (round bottom) 1 L (ball sliding S 35/20)
• Vacuum Seal: Teflon (R) Seal
• Inside bus dimensions: Inner diameter 240 x 120 mm
• Bath Material/Heater/Capacity: Aluminum (Teflon (R) Coding)/1 kW/About 5.4 L
• Connection diameter: outside diameter of cooling water nozzle and suction nozzle: 10 mm
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions: 566 x 433 x 840 (1070) mm
• Weight: 17.5 kg
• Power input/voltage: 12 A, 1.2 kVA/AC 100 50/60 Hz
• *Performance is measured at room temperature of 20 degrees Celsius and rated supply voltage.
• Code: 269720
