Spec

• Glass condenser for low boiling point solvents, direct trap
• Dehumidification capacity: Max. 150 mL (liquid recovery)
• Minimum temperature reached: -30 degrees C
• Safety features: leakage, overcurrent breaker, refrigerator overload, refrigerator high-pressure switch
• Included Features: Standby Lamp
• Refrigerator/Refrigerant: Air-cooled output: 100 W/R 134 a
• Trap Tank/Cooling Coil Material: SUS 304
• Tank Inner Dimensions/Capacity: Inner diameter 90 x 145/0.85 L
• Glass capacitor connection diameter: outer diameter 10 mm
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions: 183 x 282 x 376 (490) mm/* The dimensions in () are the values when a glass capacitor for low-boiling solvent is installed.
• Weight: approximately 15 kg
• Power input/voltage: 5.4 A, 540 VA/AC 100 V 50/60 Hz
• *Performance is measured at room temperature of 20 degrees Celsius, rated power supply voltage of 100 VAC at 50/60 Hz, 98 wt% of ethanol at 850 mL, with stirring and with lid. Performance varies dep***ing on room temperature, type of secondary refrigerant, etc.
• *The lowest temperature reached at room temperature of 35 degrees Celsius is -20 degrees Celsius.
• *It can not be ***d as a freeze-dryer.
• Code: 257440
