Spec

• Direct trap with can body cooling system
• Can wall material: SUS 304, Special Teflon (R) coating
• Dehumidification capacity: Max. 500 mL (liquid recovery)
• Minimum temperature reached: -40 degrees C
• Safety features: refrigerator high-pressure switch, refrigerator overload relay, ground fault and overcurrent breaker
• Refrigerator/Refrigerant: Air-cooled output: 450 W/R 404 A
• Trap packing material: Neoprene rubber
• Lid with Nozzle/Drain Cock Material: SUS 304, Teflon (R)/SUS 316, Teflon (R)
• Donon Nozzle Material: SUS 304
• Tank Inner Dimensions/Capacity: Inner diameter 90 x 225 mm/approx. 1.4 L
• Connection diameter: 10 mm (Lid with nozzle, drain nozzle, accessory nozzle)
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions: 200 x 450 x 600 mm
• Weight: approximately 31 kg
• Power input/voltage: 5 A, 500 VA/AC 100 V 50/60 Hz
• *Performance is measured at room temperature of 20 degrees Celsius, rated supply voltage, 50 Hz, with lid.
• *The minimum temperature to reach is the inner can wall temperature.
• Code: 227480
