Spec

• Available heating media: tap water, ethylene glycol, niveline (R), ethanol
• Temperature Adjustment Range/Accuracy: - 30 ~ 80 degrees C, +/- 0.03 degrees C (Room temperature: 20 degrees, 40 degrees)
• Cooling capacity (at liquid temperature): 0 degrees C/680 W (584 kcal/h), -30 degrees C/150 W (129 kcal)
• Temperature gradient: 1.0 ~ 0.1 degrees C/min (80 to 10 degrees Celsius, water), 1.2 ~ 0.1 degrees C/min (80 to 0 C, Kniveline (R)), 1.0 ~ 0.1 degrees C/min (20 to -20 degrees C, ethanol), 0.4 ~ 0.1 degrees C/min (20 to -30 degrees C, ethanol),
• External circulation capacity (50 Hz): maximum flow 6.7 L/min, maximum head 2.9 m (Discharge pressure: 0.03 MPa, water)
• Temperature control: P.I.D control, SSR output
• Temperature sensor: Platinum temperature resistor Pt 100 ohm
• Temperature setting and display: Numeric keypad input method, minimum setting digit 0.01 degrees C: Digital display
• Program functions: 1. Constant value operation (normal mode) 2. Auto start 3. Auto stop (1 minute to 99 hours and 59 minutes) 4. User programs A (3 patterns), B (4 patterns) (1 pattern: Max. 10 segments, 1 minute to 99 hours 59 minutes/1 segment)
• Safety features: Self-diagnostic function (Low water level, sensor error, SSR failure, overheating, heater break, cooling failure, power failure warning, program gradient failure), leakage/overcurrent breaker, overload relay
• External input/output: RS -232 C connection terminal, external temperature sensor terminal
• Heater: 1 kW (SUS 316 L)
• Refrigerator/Refrigerant: Air-cooled output: 650 W/R 407 C
• Cooling Coils: Copper-Nickel-Plated
• External circulation nozzle: Discharge port 10.5 mm outer diameter hose port (with stop valve), return port (Rc 1/4) 10.5 mm outer diameter hose port
• Water tank material: SUS 430 J 1 L
• Tank Inside Dimensions/Tank Capacity: 250 x 295 x 180 mm/13 L
• Effective dimensions in tank: 200 x 125 x 145 mm
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions: 360 (375) x 470 (540) x 795 mm/* Dimensions in () include projections.
• Weight: approximately 52 kg
• Power input/voltage: 20 A, 2.0 kVA/100 VAC 50/60 Hz
• *Power plug not included.
• *Performance is measured at room temperature of 20 degrees Celsius, clean water, rated power supply voltage, 50 Hz and no load.
• Code: 127920
