Spec

• Cooling/Circulation System: Air Cooled/Sealed System Directional Circulation
• Temperature setting range: - 10 ~ 35 C (without heater)
• Temperature control accuracy: below +/- 2 degrees C
• Cooling capacity (at liquid temperature): 20 degrees C/3000 W (2580 kcal/h), 10 degrees C/2500 W (2150 kcal/h)
• External circulation capacity (50/60 Hz): maximum flow rate 23.5/27 L/min, maximum head 9.5/13 m (discharge pressure: 0.09/0.13 MPa)
• Temperature control: Capillary tube capacity switching control + refrigerator ON-OFF control
• Temperature sensor: thermistor
• Temperature setting and display: Sheet key input and digital display
• Safety functions: Leakage/overcurrent breaker, circulating pump thermal protector, temperature rise lower limit alarm, temperature controller self-diagnostic function, sensor malfunction, refrigerator overload, refrigerator high pressure switch, refrigerator protection timer, circulating hydraulic pressure abnormal alarm (optional), circulating water flow low alarm (optional)
• Accessory functions: bypass valve, flow control valve
• Emergency stop button: standard maintenance
• External output: external temperature sensor terminal, temperature recorder output terminal, alarm output terminal, alarm items: temperature rise lower limit, temperature controller self-diagnosis function, sensor malfunction, refrigerator overload, refrigerator high pressure switch, refrigerator protection timer, circulating hydraulic pressure abnormal alarm (optional), circulating water flow rate decrease alarm (optional), remotely operated output terminal
• Refrigerator/Refrigerant: Air-cooled output: 1.1 kW/R 407 C
• Circulation pump: Magnet pump output 41/59 W (50/60 Hz)
• Cooling Coil: SUS 316 L
• External circulation nozzle: both discharge port and return port (Rc 1/2 female screw) 16 mm outer diameter hose port
• Water Tank Material/Inside Size/Capacity: SUS 304/280 x 270 mm/16.5 L (Liquid Amount: 14 L)
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions: 450 (555) x 515 x 1010 (1025) mm/* Dimensions in () include projections.
• Weight: 84 kg
• Power input/voltage: 10 A, 2.0 kVA/200 V AC, single-phase 50/60 Hz
• Power utility: 200 VAC single-phase 15 A capacity
• *Power plug not included.
• *Performance is measured at room temperature of 20 degrees Celsius, city water, rated power supply voltage, 50 Hz and no load.
• *Cooling capacity is +/- 10% of display capacity.
• Code: 270150
