Spec

• Air-Cooled/Sealed Directional Circulation
• Corresponding circulating water: tap water, ethylene glycol, nibline (R), etabline (R)
• Temperature setting range: - 20 ~ 30 C (without heater)
• Temperature control accuracy: +/- 2 degrees C
• Cooling capacity (at liquid temperature): 20 degrees C/1400 W (1204 kcal/h), 10 degrees C/1200 W (1032 kcal/h), -10 degrees C/650 W (599 kcal/h)
• External circulation capacity (50/60 Hz): maximum flow rate 12/14 L/min, maximum head: 9.5/13 m
• Temperature control: Refrigerator ON-OFF control
• Temperature setting/display: Sheet key input/digital display, minimum digit 1 degree C
• External input/output: Alarm output (no voltage a contact), Remote control input (no voltage contact)
• Safety features: Leakage/overcurrent breaker, refrigerator high-pressure switch, overload relay holding circuit, refrigerator protection timer, temperature controller self-diagnostic function, circulating pump thermal protector, f*** for service outlet
• Accessory function: With flow stop valve, temperature display correction function
• Refrigerator/Refrigerant: Air-cooled 650 W/R 407 C
• Cooling Coil: SUS 316 L
• External circulation nozzle (both discharge and return ports): One-touch connector inner diameter 10 mm, one-touch hose nozzle outer diameter 10 mm
• Water Tank Materials, Dimensions, Capacity: SUS 304, Inner Diameter 280 x 270 mm, 16.5 L (Liquid Amount 14 L)
• Service Outlet: 100 VAC Max. 4 A1 Unit
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions: 340 (354) x 384 x 851 (910) mm/* Dimensions in () include projections.
• Weight: approximately 43 kg
• Power input: 11 A, 1.1 kVA
• Power supply voltage: 100 VAC 50/60 Hz
• *Performance is measured at room temperature of 20 degrees Celsius, rated power supply voltage and no load.
• *Cooling capacity is +/- 10% of display capacity.
• *The external circulation capacity is +/- 10% of the display capacity.
• *At room temperature of 35 degrees Celsius, the temperature to reach cooling is -10 degrees Celsius.
• Code: 249170
