Spec

• Cooling/Circulation System: Air Cooled/Sealed System Directional Circulation
• Temperature setting range: - 20 ~ 20 C (without heater)
• Temperature control accuracy: +/- 1 degree C to
• Cooling capacity (at liquid temperature): 10 degrees C/740 W (636 kcal/h), -10 degrees C/360 W (309 kcal/h)
• External circulation capacity (50/60 Hz): maximum flow rate 10/12 L/min, maximum head: 9.5/13 m
• Temperature control: Refrigerator ON-OFF control
• Temperature setting/display: Sheet key input/digital display, minimum digit 1 degree C
• Safety functions: Leakage/overcurrent breaker, refrigerator overload relay holding circuit, refrigerator protection timer, temperature controller self-diagnostic function, circulation pump thermal protector, flow rate switch
• External input/output: Communication terminal for evaporator (only for N -1210 B series)
• Refrigerator/Refrigerant: Air-cooled output: 470 W/R 407 C
• External circulation nozzle: One-touch connector inner diameter 10 mm, one-touch hose nozzle outer diameter 10 mm
• Water tank capacity: about 2 L
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions: 232 (240) x 490 (505) x 600 mm/* Dimensions in () include projections.
• Weight: approximately 37 kg
• Power input/voltage: 8 A, 800 VA/AC 100 50/60 Hz
• *Performance is measured at room temperature of 20 degrees Celsius, rated supply voltage, 50 Hz and no load.
• *Cooling capacity is +/- 10% of display capacity.
• *The external circulation capacity is +/- 10% of the display capacity.
• *Pure water can not be ***d.
• Code: 261580
