Spec

• Temperature adjustment range: - 40 ~ 0 degrees C
• Temperature control accuracy: within +/- 0.5 degrees C (center of tank)
• Speed range: 100 ~ 800 rpm
• Temperature control: Heater: P.I.D control, Refrigerator: Continuous operation
• Sensor: T thermocouple
• Temperature setting and display: Sheet key input digital setting and display
• Safety features: Self-diagnostic (Heater disconnection, sensor malfunction, upper and lower limit temperature alarm, SSR malfunction, motor malfunction, memory malfunction, power failure alarm, low water level), refrigerator protection timer
• Heater: 250 W
• Stirring motor: Speed control motor output 15 W
• Refrigerator/Refrigerant: Air-cooled output: 450 W/R 404 A
• Tank Inner Dimensions/Capacity: Inner diameter 140 x 135 mm/2.1 L
• Water tank material: SUS 304
• Maximum Capacity/Maximum Diameter of Container Used: 300 mL/95 mm
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions: 350 (380) x 490 x 380 (480) mm/* Dimensions in () include projections.
• Weight: approximately 29 kg
• Power input/voltage: 6.7 A 670 VA/100 VAC 50/60 Hz
• *Performance is measured at room temperature of 20 degrees Celsius, rated supply voltage, 50 Hz and no load.
• *The temperature adjustment range may not be reached due to the supply voltage in an ambient temperature environment where the room temperature is below 10 degrees Celsius or above 30 degrees Celsius.
• Accessories: 1 Teflon (R) stirrer (20 mm), clamp (tightening phi 20 ~ 85 mm), tank lid
• Code: 182210
