Spec

• Cooling with aluminum blocks
• Temperature control range: -100 degrees Celsius to room temperature, optional - 100 ~ 50 degrees Celsius when heater unit is installed
• Temperature setting range: - 100 ~ 50 deg.
• Temperature control accuracy: within +/- 2 degrees C (at aluminum block temperature and no load)
• Cooling rate (time to reach): 20 degrees C to -100 degrees C (about 40 minutes)
• Speed range: 100 ~ 800 rpm
• Temperature control: P.I.D control
• Temperature setting and display: Sheet key input, minimum setting digit 1 degree Celsius, digital setting and display
• Safety features: Leakage/overcurrent breaker, cooling unit exhaust heat temperature upper limit setting
• External input/output: External temperature sensor terminal
• Stirring motor: DC brushless motor output 15 W
• Temperature sensor: Platinum temperature resistor Pt 100 ohm
• Refrigerator/Refrigerant: Stirling cooler 150 W helium (non-CFC)
• Aluminum block set: Sold separately
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions: 220 x 600 x 355 mm
• Weight: approximately 24 kg
• Power input/voltage: 2.5 A 250 VA/100 VAC 50/60 Hz
• *An aluminum block set is required for ***.
• *Performance is measured at room temperature of 20 degrees Celsius, rated power supply voltage, 50 Hz, stirring in the tank at 800 rpm, with no load.
• The minimum temperature to reach the sample temperature is -80 degrees Celsius. When controlling the sample temperature with an external or sample temperature sensor, do not set the temperature lower than -80 degrees Celsius.
• Code: 263160
