Spec

• Downstream airflow system
• Temperature control range: 0 ~ 50 degrees C (with lights off), 10 ~ 50 degrees C (with all lights on), 15 ~ 50 degrees C (with high-light unit)
• Illumination adjustment range: 0 to about 30,000 L x 6 steps (step dimming)
• Temperature and humidity control accuracy: Mode 1 (normal mode): 0.5 degrees Celsius, Mode 2 (Eco mode): 1.5 degrees Celsius
• Accuracy of illuminance distribution: +/- 10%
• Temperature control: Mode 1 (normal mode): Heater control P.I.D control SSR output, Mode 2 (Eco mode): Refrigerator control ON-OFF control
• Temperature/Humidity/Illuminance Settings/Display: Sheet key input/Digital display Minimum digit 0.1 degrees C/0.1% RH Accumulated time (1 to 999 days, 23 hours, 59 minutes) Mass display/Graphic display (switching)
• Defrosting function: 1. Automatic control system (during operation, 4 patterns) 2. Forced manual system (Manual Start, Automatic Stop) 3. Timer control system (Auto Start, Stop, Repeat) 4. Defrost heating and cooling
• Program functions: Auto start, Auto stop, User program, 24 hour program, Auto start + User program, Consolidated program
• Other functions: RS -232 C communication terminal, recorder output terminal (Temperature/humidity, illuminance, CO2: custom-made), alarm output terminal (contact/non-voltage type), temperature and humidity display calibration, maintenance mode, sterilization light, interior lighting
• Heater: 900 W
• Refrigerator/Refrigerant: Air-cooled output: 400 W/R 404 A
• Interior dimensions (width x depth x height): 520 x 520 x 1085 mm
• Internal volume (L): about 290
• Interior: SUS 430 J 1 L
• Shelf Board Load Capacity, Material, Number of Levels: Uniform Max. 25 kg/Sheet, PE Coating, 17 Levels
• Number of Shelf Boards Attached/Shelf Pitch: 3/50 mm
• Cable hole/Service outlet: 1 right side inside diameter 40 mm/Service outlet (Outside, 2 pieces, total Max. 1A)
• Operating ambient temperature: 5 ~ 35 degrees C
• Outer dimensions (width x depth x height): 720 (750) x 854 (918) x 1810 mm/* () Inner dimensions include projections.
• Weight (kg): approximately 235
• Power input/voltage: 22 A, 2.2 kVA/100 VAC 50/60 Hz
• *Power plug not included.
• Code: 264610
• *Performance is measured at room temperature of 20 degrees Celsius, rated supply voltage, off, 50 Hz and no load. Performance notation for temperature and humidity distribution conforms to JIS C 60068 -3 -6 JTM K 09 -2009.
