Spec

• Air Jacket Natural convection formula
• Temperature Control Range: R.T. + 5 to 60 ° C
• Temperature Adjustment Accuracy: ± 0.5 ° C (At 37 ° C)
• Temperature Distribution Accuracy: ± 3.5 ° C (At 37 ° C)
• Temperature distribution (at 37 degrees C): Spatial temperature deviation 2.3 ° C, Temperature gradient 3.4 ° C
• Timer time setting range: 0 to 99 hours 59 minutes
• Temperature Control/Setting/Display: P.I.D Control SSR Output/Sheet Key Input/Digital Display (Temperature Display Correction, Auto Start, Auto Stop 1 and 2, Power Failure Recovery Setting)
• Safety Function: Alarm Function (Upper limit temperature, door open, sensor, power failure, temperature uncontrollable, watchdog), Indep***ent Excess Temperature Rise Prevention System (Fixed at 70 ° C), F***
• Heater: 100 W
• temperature sensors: thermistors
• Interior, Inner Door: SUS304
• inner dimension (Width x Depth x Height) : 310 x 240 x 220 mm
• Inner volume (L): about 16
• shelf board Load tolerance/material: Equal Distribution Max. 3kg/Sheet/PE Coating
• Number of shelf board Supplies/Shelf pitch/number of step: 2 pieces/60 mm/3 stages
• Operating ambient temperature range: 5 to 35 ° C
• external dimension (Width x Depth x Height): 395 x 355 (375) x 420 mm/* The Dimensions in () includes bumps.
• Weight (kg) : about 14
• power supply Input/power supply Voltage : 1.5 A 150 VA/AC100V 　50/60 Hz
• Code Number: 197980
• *Performance measured at R.T. 25 ° C, rating power supply Voltage, 50Hz, and no load.
• *There may be a difference between the set temperature and the actual temperature due to the characteristics of the product.
• *When the shaker is inserted into the chamber, the temperature control range is + 10 ° C or higher. Also, inside temperature may fluctuate.
• *Performance description of temperature distribution conforms to JIS C 60068 -3 -5 JTM K07 -2007 (Japan Testing Machine Industry Association, performance testing method and performance display method for temperature testing tank).
• *power supply input does not include internal outlet capacity.
