Spec

• Natural convection system
• Temperature adjustment range: 40 ~ 250 degrees C
• Temperature control accuracy: +/- 1 ~ 5 degrees C
• Temperature distribution accuracy: +/- 11/+/- 19 degrees C (at 100/200 degrees C)
• Temperature reach time: 60 to 70 minutes
• Microcomputer with temperature control, setting, display and auto tuning function P.I.D control SSR output, sheet key input, digital display
• Timer program function: Auto start, Auto stop, Step (up to 8 steps), Repeat, 24 cycles, Temperature gradient (10 segments)
• Safety features: Door opening, upper/lower temperature, sensor failure, heater break, setting error, temperature gradient, power failure, earth leakage, overcurrent breaker, indep***ent overrise detector
• Heater: Stainless steel sheath heater 1.2 kW
• Interior dimensions (width x depth x height): 450 x 450 x 400 mm
• Storage capacity (L): 81
• Shelf Board Load Capacity, Material: Uniform Distribution Max. 15 kg/Sheet, SUS 304
• Shelf Plates Included: 2
• Number of shelf pitch stages: 30 mm, 12 stages
• Observation Window (mm): 180 W x 300 H (Double Glazed)
• Interior and Door Packing Materials: SUS 430 J 1 L, Silicon
• Vent/Cable hole: top 2 places, 37 mm/right side, 37 mm
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions (width x depth x height): 550 (577) x 560 (625) x 820 mm/* Dimensions in () include projections.
• Mass (kg): about 58
• Power input/rated power: 12.5 A 1.25 kVA/100 VAC 50/60 Hz
• Power cord: 2.8 m
• *Performance is measured at room temperature of 20 degrees Celsius, rated power supply voltage, 50 Hz, no load and with the exhaust port closed.
• *One shelf board is fixed to the bottom shelf.
• Code: 181620
