Spec

• Operation form: constant temperature
• Operating temperature range: R.T. + 5 °C, to 70 °C
• Temperature Adjustment Accuracy: ± 0.2 °C
• Shaking angle: 60 °
• Shaking speed: 20 rpm to 70 rpm (1 rpm unit)
• Setting items and setting ranges
• Preparation time: 0 or 5 minutes to 300 minutes
• Shaking time: 1 min. to 99 min. (ON time), 0 min. to 99 min. (OFF time)
• Absorbance determination interval: 1 minute to: 99 minutes
• Operation time: 1 hour to 249 hours 59 minutes
• Ambient operating temperature: 5 °C to 35 °C (non-condensing)
• Absorbance measurement range: O.D. value not more than 2.0
• temperature controller: Microcomputer PID Control
• Temperature Sensor: Platinum Temperature Measuring Resistor Pt 100 Ω
• Heater: Silicone rubber heater
• Heater capacity: 100 W
• Shaking Method: Monode Type Arc Reciprocating Motion
• Culture block part: Aluminum conductor
• Culture Block Culture Tube Insertion Part: Small L-type Culture Tube 6 pieces (Or test tube, vial bottle)
• Light source of detector: tungsten lamp 6 pieces
• Detector Light Receiver: Silicon Photodiode 6 pieces
• Detector filter: Glass filter 660 nm, 6 pieces
• record
• Data is recorded and stored in separately sold personal computer and printers.
• Up to 6 devices can be connected.
• Data processing is also possible.
• Safety device: Self-diagnostic function (Overheating, temperature sensor disconnection, heater disconnection), indep***ent overheat protection device, overcurrent breaker
• External input/output signal terminal: RS -232 C (Output of temperature and absorbance data by personal computer)
• external dimensions (Installation Space): W 410 mm x D 325 mm x H 160 mm (W 410 mm x D 406 mm x H 160 mm)
• power supply (50Hz/60Hz): AC100V 3A
• Mass: about 10 kg
• Accessories: Small L-type Culture Tube 6 pieces, Culture Tube Cap 6 pieces, power cord 1 piece
