Spec

• Purification method: Ion exchange → distillation → (ion exchange * sold separately) → filtration
• Purified Water: Distilled Water, Ion-exchange Water, (High-purity Ion-exchange Water * Sold Separately)
• Distilled water purification rate: about 10 L/h
• Distilled water sampling rate: Max. 3 L/min (with water sampling rate variable function)
• Ion exchange water sampling rate: approx. 0.5 L/min to 1 L/min
• Distilled water sampling Set range: 0.1 L to 100.0 L (0.1 L units) or 10 mL to 9,990 mL (10 mL units)
• Ion Exchange Water Sampling Quantity Setting Range: 0.1 L to 100.0 L (0.1 L Units)
• Ambient operating temperature: 5 °C, to 35 °C
• Boilers: Superhard Glass
• Cooler: Superhard Glass
• Heater: Ceramic heater
• Heater capacity: 1.5 kW 6 pieces
• High-purity distilled water purification mechanism: RFS 362 NC/363 NC/562 NC/563 NC: Air Vent Filter 1 piece, Air Chamber 2 pieces, Air pumps 1 piece
• Raw Water Filter: Pretreatment Cartridge Filter 1 piece
• Ion Exchange Plastic Cartridge: One-Touch Connection Type Cartridge (Mixed Bed Type 1.6 L) 2 pieces
• Distilled water final filter: Hollow fiber filter (0.04 μm) Each 1 piece
• Ion Exchange Water Final Filter: Hollow Fiber Filter (0.04 μm) Each 1 piece
• Air vent filter for tanks: Air vent filter (Activated carbon, soda lime, PTFE membrane filter) 1 piece
• water quality meter *: Digital display (Specific resistance: Automatic temperature correction 25 °C, temperature) * Unit can be switched by μs/cm or MΩ/cm.
• Distilled water storage tank: 100 L polyethylene
• Distilled water water storage volume indication: numeric (in 1L increments) and bar graph indication
• External Water Supply Mechanism: Standard Equipment
• Sink: W 690 mm x D 268 mm x H 87 mm (Water splash mitigation net, tap water with faucet)
• Raw water pressure range: 100 for kPa, to, 490 for kPa
• Raw water required: approx. 4 L/min (7.5 L/min when using a sink faucet)
• external dimensions : W 825 mm x D 660 mm x H 1,530 mm
• power supply (50Hz/60Hz): 200 VAC Single-phase 38 A
• Required power supply Equipment: 200 VAC Single-Phase 40 A
• Mass: about 111 kg
• Accessories: Pretreatment Cartridge Filter 1 piece, Ion Exchange Plastic Cartridge (2 pieces Pack) 1 Box, Hollow Fiber Filter 2 pieces, Main Mouth 1 piece, Water Supply Hose (With Connection Unit, inner diameter 9 mm x outer diameter 17 mm, 2 m) 1 piece, Water Splash Mitigation Net 1 piece, Tray 1 piece, Hollow Fiber Filter Cap 2 pieces, Signal Connector 1 piece, Airvent Filter 2 pieces
