Spec

• convection formula : Blower type (Left Callout, Horizontal)
• Operating temperature range: 50 °C, to 300 °C
• Temperature Adjustment Precision: ± 0.2 °C at 300 °C
• Temperature variation: ± 1 °C at 300 °C
• Temperature distribution accuracy: ± 3 °C at 300 °C
• Temperature gradient: 6 °C at 300 °C
• Spatial temperature deviation: 4 °C at 300 °C
• Temperature rise time: about 55 minutes, from R.T. to 300 °C
• Ambient operating temperature: 5 °C, to 35 °C
• temperature controller: Microcomputer PID Control (TC-EVI System)
• Operation Style: Standard Value Operation, Timer Operation (Auto Stop, Cooling) 1 minute, to 99 hours 59 minutes
• Temperature sensor: K class thermocouple
• Heater: Stainless Steel Sheath Heater
• Heater capacity: 2.1 kW
• Blower Fan: Sirocco Fan (Aluminum)
• Interior: SUS304
• Door Packing: Silicone Rubber * Change to Fluororubber
• Safety device: Self-diagnostic function (Overheating, temperature sensor error, heater disconnection, SSR short circuit, ambient temperature error), indep***ent overheat prevention device, inverter failure, control circuit protection f***, key lock function, overcurrent/leakage breaker, door switch
• inner dimension (Valid Dimensions): W 450 mm x D 450 mm x H 450 mm (H 397 mm)
• external dimensions : W 1,085 mm x D 675 mm x H 785 mm
• Internal Volume: Approximately 91 L
• number of shelves pitch : 7 stages 50 mm
• Exhaust Port: φ 72 mm (Top) * When Stacking in Two Columns, φ 65 mm (Left Side)
• Measurement Hole: φ 28 mm Left Side 1 location
• power supply (50Hz/60Hz): 200 VAC Single-phase 13.5 A
• Required power supply Equipment: 200 VAC Single-Phase 20 A
• Mass: about 115 kg
• Accessories: shelf board 2 pieces, Shelf Bracket 4 pieces, Fixed metal bracket 4 pieces (Mounting Screw 8 pieces)
