Spec

• Tank Shape: square shape
• Operating temperature range: R.T. + 5 °C, to 95 °C
• Temperature Adjustment Accuracy: ± 0.3 °C at 60 °C (When Stirring)
• *There is no stirring function.
• Temperature distribution accuracy: ± 1 °C at 60 °C (while stirring)
• *There is no stirring function.
• Temperature rise time: about 30 minutes, from R.T. to 95 °C
• Ambient operating temperature: 5 °C, to 35 °C
• temperature controller: Microcomputer PID Control
• Temperature Sensor: Platinum Temperature Measuring Resistor Pt 100 Ω
• Heater: SUS316L Pipe Heater
• Heater capacity: 800 W
• Tank: material, SUS304
• Safety device: Self-diagnostic function (Overheating and temperature sensor disconnection), overheat protection device, overcurrent protection f***
• tank inner size : W 180 mm x D 180 mm x H 120 mm
• external dimensions : W 260 mm x D 350 mm x H 165 mm
• tank inner capacity (when full of water): about 3.8 L
• power supply (50Hz/60Hz): AC100V 8.1 A
• Required power supply Equipment: AC100V 15 A
• Mass: about 2.8 kg
• Accessories: Thermometer Holder 1 piece, Overcurrent Protection F*** 1 piece, can stone removal agent (30 g) 1 Pack
